Open the set. Count the findings.

"TOTAL IMPERVIOUS AREA" is off by 8,400

The line items sum to 164,050, but the table states 172,450 — a difference of 8,400. Quantity errors carry through to bid documents, so reviewers check these.

48,600 + 92,400 + 14,150 + 8,900 = 164,050, stated 172,450

"TOTAL" percentages sum to 97.8%, not 100%

The listed percentages total 97.8%, leaving 2.2% unaccounted for. Either a land-use category is missing from the table or one of the figures is wrong.

41.6 + 28.6 + 18.5 + 9.1 = 97.8%

Sheet states 1"=30' but its scale bar measures 1"=40'

The graphic scale bar on this sheet was measured from the drawn geometry at 1"=40', while the sheet states 1"=30' — a 25% disagreement. One of the two is wrong, and anyone scaling a distance off this sheet gets that error. This is most often a sheet copied from another where either the bar or the caption was updated and the other was not.

page 4: bar measures 1.8000 pt/ft, title block states 2.4000 pt/ft

I-215: D-4.23 is published as "Type 'E' Inlet Frame & Grate", not a TYPE 'S' INLET

I-215 is typed "TYPE 'S' INLET" and cites detail D-4.23. Howard County publishes D-4.23 as "Type 'E' Inlet Frame & Grate". The only number it publishes under this row's own type — "Type 'S' Inlet" — is D-4.24, which I-214 on this sheet cites for the same type. A contractor builds to the drawing the schedule points at, so a detail number naming a different structure is worth confirming before submittal.

I-215 (sheet page 11): TYPE 'S' INLET, DETAIL D-4.23; Design Manual Volume IV publishes D-4.23 as "Type 'E' Inlet Frame & Grate" and D-4.24 as "Type 'S' Inlet" (2017 edition); I-214 on the same sheet cites D-4.24

I-219: detail D-4.99 is not in Volume IV

I-219 cites standard detail D-4.99, which does not appear among the 331 numbers in Howard County Design Manual Volume IV's table of contents. Either the number is a typo, or the plan was drawn against a different edition of the manual than the 2017 edition we hold.

I-219 (sheet page 11): DETAIL D-4.99; not found in Design Manual Volume IV

MH-221: outgoing invert is 0.35' above the incoming

The schedule gives MH-221 an outgoing invert of 480.90 and an incoming invert of 480.55. Water would have to run uphill through the structure. This is usually two elevations swapped between the IN and OUT columns, or a transposed digit.

MH-221 (schedule on page 11): INV IN 480.55, INV OUT 480.90

ES-224: outgoing invert differs between sheets

ES-224 appears in more than one schedule with a different outgoing invert: 477.40 in one place and 477.70 in another. One of them was revised and the other was not — the reviewer will find whichever disagrees with the profile.

ES-224: page 11 says 477.70; page 13 says 477.40

I-118: inflow 498.15 is above every rim in the schedule

I-118 is shown receiving a pipe at 498.15, but the highest rim stated anywhere in this schedule is 496.35 (I-214). No structure listed here could discharge into it, because the pipe would have to leave above its own cover. Either the inflow is a transposition, or the structure feeding it is not in this schedule — check the sheet's remarks for a connection to a separate system.

I-118 (sheet page 11): INV IN 498.15; highest rim in schedule 496.35 at I-214

C-300 title differs between index and title block

The index calls C-300 "SITE LAYOUT PLAN" but the title block reads "SITE LAYOUT AND PAVING PLAN". A reviewer cross-referencing the index will flag this. Round 1 of adjudication (2026-09-10): a practising civil engineer judged 15 findings of this rule on 6 real Howard County plan sets. 10 were real differences a reviewer could raise: typos, abbreviations, a changed word, a title missing half its words. The other 5 were not. 3 compared the index against a street or utility label, because the sheet prints its title smaller than the labels around it or only in a hidden text layer, and 2 differed by nothing more than a filler word or two abbreviations of one term. This rule now looks for the index title in the title block before reporting, and treats E&S and ESC as one word; a sheet printing a PLAN the index leaves out is agreement, while an index claiming a word the sheet does not print is still reported. When the title-block text quoted here shares no word with the index title, open the sheet: on the real sets measured, that quote was a label we read, not the sheet title.

index: "SITE LAYOUT PLAN" | title block: "SITE LAYOUT AND PAVING PLAN"

Sheet C-304 plotted 22" x 34"; Howard County, Maryland requires 24" x 36"

Sheet C-304 in this set measure 22" x 34". Howard County, Maryland requires plan sheets to be 24" x 36" — Howard County DPZ — SDP Signature Blocks, Standard Charts, etc. (2023-02), "STANDARD SITE DEVELOPMENT PLAN SHEET" figure (p. 5): “ALL SITE DEVELOPMENT PLAN SHEETS MUST BE 24" X 36" IN SIZE”. A sheet on the wrong stock is caught at intake rather than at review, so it costs a resubmission cycle for a defect that is a re-plot to fix. Two causes account for every instance found in this county's own archive: a package prepared by a sub-consultant — a retaining wall or a lighting design — bound into the set on that consultant's own sheet size, and a plot configuration that was never set to the county's sheet.

page 8: media box 22" x 34"; "STANDARD SITE DEVELOPMENT PLAN SHEET" figure (p. 5) requires 24" x 36" (±0.5")

C-401 is bound before C-402

Sheet C-401 appears on page 10, after C-402 on page 9. Sheet numbers must ascend through the set.

page 9: C-402 -> page 10: C-401

Page 12 calls itself sheet 11

The title block on page 12 reads "SHEET 11 OF 17", but the rest of the set numbers that page 12. A title block copied forward without updating the position leaves two sheets claiming the same place in the set.

page 12: "SHEET 11 OF 17" | expected SHEET 12

STORMWATER MANAGEMENT PLAN is drawn at 1"=60'; Howard County, Maryland requires 1"=10' to 1"=50'

This sheet states its scale as 1"=60'. Howard County, Maryland requires plan sheets to be drawn at 1"=10' to 1"=50' — Howard County DED Checklist — Site Development Plan, Commercial (Rev Aug 2025), section II.D.1: “Plan Scale 1” = 10’ to 1” = 50’”. A scale outside the published range is one of the cheapest things for a reviewer to return a set over, and one of the most expensive to fix afterwards, because re-plotting the sheet moves every label and callout on it. If the range was waived for this project, say so on the sheet.

page 13 (“STORMWATER MANAGEMENT PLAN”) states “SCALE 1" = 60'”; II.D.1 requires 1"=10' to 1"=50'

C-601 is in the set but missing from the index

Page 17 carries sheet number C-601 ("LANDSCAPE NOTES AND DETAILS"), but the sheet index does not list it. Add it to the index.

title block 'C-601' on page 17, absent from index
